USB High Definition Digital Video Microscope 8x-9032x YSC US209




YSC PowerScope US209 is the ultimate digital microscope that can be customized with various camera, lighting, stand, software, and measurement options. The lens offers superior resolution and depth of field with detent click stop feature, which is ideal for video measurement application. It has a wide zoom ratio and standard internal coaxial lighting port for bright field coaxial lighting applications. Various cameras (HD 1080p and USB megapixel [from 1.3MP to 32MP], VGA output, HDMI output, Internal SD memory and HD high definition), lighting (LED, halogen and fluorescent) and stand options can be configured for your system. This system can capture still images and record motion video. Measurement software, image processing software, and X-Y-Z measurement stages are available. The system can also be configured with motorized zoom lens and stage.

Applications
· Assembly
· Production
· Quality Control
· Failure Analysis
· Process Control
· Measurement
· SMT
· Electronics
· Medical Device
· Machining
· Aerospace
· Natural Science
· Training
· Documentation

Benefits
· High resolution video for viewing and documentation
· Healthy Ergonomics: Less eye fatigue and neck stress
· Great Depth of Field
· Large LCD for discussion or training purpose
· Real Time Full Motion Video Display
· Image Capture: Save images in jpg, bmp or tiff files
· Record Motion Video
· Long working distance for assembly or inspection applications
· Wide zoom ratio with constant focus
· Full camera, lens and lighting options
· Measurement software and XY measurement stage options
· Stand alone image and video capture device options
· Different stand options
· Adjustable viewing angles
· Adjustable high intensity LED
· Fluorescent or halogen lighting options

Stand Options

  ST-061 ST-021 ST-023 ST-071 ST-041

Camera Options

HD High Definition CCD or 3CCD USB CCD or CMOS
1.3 to 32 MP
HDMI Output VGA Output
with SD Memory

LCD Monitor Options

SONY 15 Inch LCD 15 Inch LCD 10 Inch LCD 8 Inch LCD

Accessories

USB Capture Device Computer XY Measurement Stage XY Stage Portable Image and Video
Capture Device

Image Pro Ultra SoftwareImage Software

Real-Time Multiple Measurement and
Image Processing Software

Grid Overlay:
· Square
· Scale
· Cross Hair
· Concentric Circle
· Center Square
Grid Overlay


3D Surface Plot



Live Multiple Measurements
Measurement Tools:
· Live Measurement
· Multiple Measurements
· Calibration Manager
· Line Distance
· Point to Point Horizontally
· Horizontal Lines
· Point to Point Vertically
· Vertical Lines
· Parallel Lines
· Poly Line
· Center to Center Circle
· Circle
· Center Circle
· 3 Point Circle
· Ellipse
· Rectangle Area
· Polygon Area
· 2 Line Angle
· 3 Point Angle


    · Distance
    · Point to Point
    · Circle Radius
    · Circle Area
    · Angle
    · Line Width
    · Parallel Line Measurement
    · Area
    · Motion Video Recording
    · JPG Image Capture
Multi Focus

    · Combine different plan focus images into one
    · Improve depth of field over single image capture
Image Tiling

    · Still image mode
    · Real-time video mode
    · Manual tiling
    · Auto tiling
    · Expand your current picture taking capabilities
    · Increase the field of view of your existing camera

Technical Specifications


Lens Objective

L009-0.5X

STANDARD (1X)

L009-2X

L009-10X

L009-50X

Video Magnification with 19" Monitor and 1/1.8" CCD

16x - 190x

31x - 380x

63x - 759x

387x - 1806x

1935x - 9032x

Diagonal Field of View

30.69 - 2.54 mm

15.34 - 1.27 mm

7.67 - 0.64 mm

1.25 - 0.27 mm

0.249 - 0.053 mm

with 1/1.8 inch CCD

1.21 - 0.10 inch

0.60 - 0.05 inch

0.30 - 0.03 inch

0.05 - 0.01 inch

0.010 - 0.002 inch

Working Distance

165 mm
(6.5 inch)

86 mm
(3.39 inch)

37 mm
(1.46 inch)

33 mm
(1.3 inch)

13 mm
(0.51 inch)

N.A.

0.009 - 0.051

0.019 - 0.101

0.038 - 0.202

0.28

0.55



Lens Features

Wide Zoom Ratio with Detent Click Stops or Non-Detent Click Stops

Lens Options

Manual or Motorized

Lighting Options

Internal Coaxial (Halogen or LED), Ring (Halogen, LED or diffused), Dual Arm Fiber, Side and Back Lighting

Camera Options

USB MegaPixel (up to 32MP) or HD 1080p

Stand Options

Manual or Motorized

Software Options

Video Measurement, Image Capture and Image Processing

Measurement Options

XY Measurement Stage or Z-Height

Image Files

jpg, tif, bmp


US209 Additional Lens Options:

Lens Objective

L009-0.25X

L009-0.75X

L009-1.5X

L009-5X

L009-20X

Video Magnification with 19" Monitor and 1/1.8" CCD

8x - 95x

24x - 287x

47x - 569x

194x - 903x

774x - 3505x

Diagonal Field of View

59.33 - 5.09 mm

20.23 - 1.68 mm

10.23 - 0.85 mm

2.49 - 0.53mm

0.62 - 0.14 mm

with 1/1.8 inch CCD

2.34 - 0.20 inch

0.80 - 0.07 inch

0.40 - 0.03 inch

0.10 - 0.02 inch

0.025 - 0.005 inch

Working Distance

341 mm
(13.43 inch)

108 mm
(4.25 inch)

50 mm
(1.97inch)

34 mm
(1.34 inch)

20 mm
(0.79 inch)

N.A.

0.005 - 0.025

0.014 - 0.076

0.028 - 0.151

0.14

0.42




Lens Features and Options:



L009

Manual Zoom 1:12

+

Detent-Click Stops

+

Internal Coaxial Light Port

+

Motorized Zoom and Focus

Please Call





Lighting Options:



Ring LED Lighting

+

Ring Halogen Lighting

+

Coaxial Halogen Lighting

+

Coaxial LED Lighting

+

Dual Arm Fiber Lighting

+



Click the thumbnail to expand.
